Service Menu Selection 5-151
01 Aug 2000
Figure 5-166 Response Dialog
Step 7 Press the button or the button to toggle the
Cancel parameter values.
Parameters Values
Cycle The number of completed test
cycles of the requested cycles
Status Shows the status of the
indicated cycle (Running,
Completed, Error, Canceled)
Cancel Y to cancel the test.
N to continue running the test.
Press the button to confirm the changes.
If
Y
is selected for the Cancel parameter value, the test is
cancelled. Otherwise, the test continues.
DIAGS GRIPPER TEST
Cycle : 006 of 009
Status: Running
Cancel: N<
Note
If the operation
stops, the Cancel
parameter no
longer displays.
